Physical Characteristics
Dimensions151 x 76 x 132 mm / 5.94 x 2.99 x 5.19 in.
WeightSled Reader: 438 g / 15.45 oz.
PowerBattery specification:5200 mAh removable battery
Standby: over 70 hours (keeping bluetooth connected)
Continuous use: up to 2.5 hours (UHF reading: 400 tags)
Charging time:4-5 hours (with standard adaptor and USB cable)
InterfacesUSB 3.0 Type-C
Indicator LEDPower, Work, Bluetooth
Size of adapted phoneSled Reader: Width 68~80 mm, thickness ≤ 22 mm
Others: Based on phone case or holder
Product MaterialPlastic
BluetoothBluetooth Low Energy (BLE) 5.0
Developing Environment
SDKAndroid / iOS
LanguageJava / Objective-C
ToolAndroid Studio / Xcode
User Environment
Operating Temp.-4℉~+122℉ / -20℃~+50℃
Storage Temp.-40℉~+158℉ / -40℃~+70℃
Humidity5%RH – 95%RH non condensing
Drop SpecificationMultiple 1.5 m / 4.92 ft. drops to concrete across the operating temperature range
Tumble Specification1000 x 0.5 m / 1.64 ft. falls at room temperature
SealingIP54 per IEC sealing specifications
ESD±15 KV air discharge, ±8 KV conductive discharge
Barcode Scanning
2D Imager ScannerSE2707
1D SymbologiesUPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS,etc.
2D SymbologiesPDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX), etc.
Note*This function is optional
EngineCM710-1 module based on Impinj E710
CM2000-1 module based on Impinj Indy R2000
Frequency920-925 MHz / 902-928 MHz / 865-868 MHz
ProtocolEPC C1 GEN2 / ISO18000-6C
AntennaCircular Polarized Antenna (4dBic)
Power1W (30dBm, support +5~+30dBm adjustable)
2W Optional (33dBm, for Latin America, etc.)
Fastest Read Rate900+ tags/sec
Max Read RangeImpinj E710 chip:
30m (Impinj MR6 tag, size 70 x 15mm)
28m (Impinj M750 tag, size 70 x 15mm)
31m (Alien H3 Anti-Metal tag, size 130 x 42mm)

Impinj R2000 chip:
25m (Impinj MR6 tag, size 70 x 15mm)
26m (Impinj M750 tag, size 70 x 15mm)
25m (Alian H3 Anti-Metal tag, size 130 x 42mm)
Note* Ranges are measured in the open outdoors and low interference environment, and rate is measured in a laboratory low interference environment, they are affected by tags and environment.
